Measuring

Measuring instructions external Screen roller blinds

Long and trouble-free operation of a blind depends not only on the high quality of its workmanship, but also on its correct fitting and assembly. For the blind to fit perfectly, the chosen location must be correctly and carefully dimensioned.
The following auxiliary drawings must be strictly adhered to.


  • A - WIDTH This is the width of the window opening from the outside.
  • B - HEIGHT This is the height of the window opening from the outside.
  • C1, C2, C3 - Width of the visible elements of the window frame

Dimensions A and B will be the dimensions of the finished product.

*C1 and C2 are the width of the visible window frame elements (if C1<25 mm or c2<25 assembly impossible)


Technical data

Maximum dimensions supported by boxes
Box type Max width Max height
95 3000mm 3000mm
105 3500mm* 4000mm*
125 5000mm* 5000mm*

*We cannot produce screen blinds, where both dimension exceed 3000mm. Only one can be above 3m, in example: you can order a 5000x3000, but cannot order 5000x3100, the same goes for 3100x5000.

Performance features of the system
System dimensions [mm] System properties
Height of the box: 95/105/125 Wind resistance [km/h]: 145
Surface area [m2]: 9/12/15 Solar radiation reduction: 75%
UV rays filtering: 8%

HEMA - Box 95

Box 95 - 45°Box 95 - 45°
Box 95 - 90°Box 95 - 90°
ZIP integrated guideZIP integrated guide
Bottom railBottom rail

HEMA - Box 105

Box 105 - 45°Box 105 - 45°
Box 105 - 90°Box 105 - 90°
ZIP integrated guideZIP integrated guide
Bottom railBottom rail

HEMA - Box 125

Box 125 - 45°Box 125 - 45°
Box 125 - 90°Box 125 - 90°
ZIP integrated guideZIP integrated guide
Bottom railBottom rail

*All dimensions are given in millimeters.
